T-shirt Bag Automatic Making Machine (6 Lines)
| Model | FTA3+P-32X30 | FTA3+P-40X30 | |
|---|---|---|---|
| Max Cutting Width | 9"x6 | 12"x6 | |
| Max Cutting Length | 30" | 30" | |
| Length Tolerance | mm | ±1 | ±1 |
| Thickness | mm | 0.01-0.15 | 0.01-0.15 |
| Prod. Per. Min | pc | 40-120 | 30-100 |
| Driving Motor | AC | 2hp | 2hp |
| Heater Capocity | kw | 7 | 8.5 |
| Power Required | kw | 8.5 | 10.5 |
| Dimehsion L x W x H | cm | 390 x 145 x 220 + 260 x 133 x 166 | 390 x 165 x 220 + 260 x 153 x 166 |
| Machine Weight | kg | 1400+800 | 1600+900 |
| Measurement L x W x H | cm | 260 x 155 x 225 + 270 x 143 x 176 | 260 x 175 x 225 + 270 x 163 x 176 |
| Gross Weight | kg | 1700+1000 | 1900+1200 |
