T-shirt Bag Making Machines
T-shirt Bag Making Machines
FTAAB
| Model | FTAAB 28X30 | FTAAB 32X30 | FTAAB 40X30 | |
|---|---|---|---|---|
| Max Cutting Width | 13"x2 | 15"x2 | 18"x2 | |
| Max Cutting Length | 30" | 30" | 30" | |
| Length Tolerance | mm | ±1 | ±1 | ±1 |
| Thickness | mm | 0.01-0.15 | 0.01-0.15 | 0.01-0.2 |
| Prod. Per. Min | pc | 40-120 | 40-120 | 30-100 |
| Driving Motor | AC | 2hp | 2hp | 2hp |
| Heater Capocity | kw | 1.8 | 2.2 | 3.4 |
| Power Required | kw | 2.8 | 3.5 | 5.0 |
| Dimehsion L x W x H | cm | 350 x 135 x 165 | 350 x 145 x 165 | 350 x 165 x 165 |
| Machine Weight | kg | 900 | 1100 | 1300 |
| Measurement L x W x H | cm | 225 x 145 x 170 | 225 x 155 x 170 | 225 x 175 x 170 |
| Gross Weight | kg | 1200 | 1400 | 1600 |
